CHAPTER 28
PAGE 3
MAINTENANCE MANUAL EXTRA 300/SC
PAGE DATE: 16. June 2008
28-00-00 GENERAL
Description and Operation
The fuel system (refer to Figure 1) consists of the front
center tank (2), the rear center tank (4) an acro tank (6), two
wing tanks (1&5), a fuel selector valve (3), a gascolator (9),
an electrically driven auxiliary pump (7) and an engine driven
rotary pump (8).
On the instrument panel one fuel quantity indicator for the
center tank and one for the wing tanks, the switch for the
boost pump and circuit breakers are installed (see Figure 14).
Fuel Tank Capacities
Front center tank: 54 l (14.3 US Gal.)
Rerar center tank 41 l (10.8 US Gal.)
Acro tank: 9 l ( 2.4 US Gal.)
Wing tank LH: 60 l (15.85 US Gal.)
Wing tank RH: 60 l (15.85 US Gal.)
Total capacity 224 l (29.2 US Gal.)
Unusable fuel: 3 l ( 0.8 US Gal.)
