CHAPTER 28
PAGE 30
MAINTENANCE MANUAL EXTRA 300/SC
PAGE DATE: 1. August 2014
W A R N I N G Stripping solvents can be toxic and volatile. Use only
in well ventilated areas. Avoid physical contact with
solvent and do not inhale vapors. Keep solvent contain-
ers covered when not in use.
5 Clean sealing surfaces mechanically and with Acetone.
6 Install in reverse sequence of removal after applying 3M
Brand Fuel Resistant Coating 776 (3M, St. Paul, USA) for
sealing to both sides of the sealing ring and the grooves in-
side the tank.
7 Check proper shape and installation of float wire as per para-
graph 28-40-05.
28-40-05 Float Wire
Adjustment
1 Remove the lever-type tank unit per Chapter 28-40-04.
2 Remove the float wire and bend it in form like shown in the
following Figure 14:
Figure 14 Float Wire Adjustment
