CHAPTER 31
PAGE 3
MAINTENANCE MANUAL EXTRA 300/SC
PAGE DATE: 1. August 2014
31-10-00 INSTRUMENT PANEL
Description and Operation
The instrument panel consists of an aluminium sheet which
is canted several times. It is fastened to the main fuselage
cover and the steel frame with machine screws, bolts and
special washers. The instrument panel top cover is part of the
main fuslage cover, which itself is furnished with an instru-
ment access panel as shown in Chapter 51-00-01.
Figures 1 and 2 in connection with the related charts on the
next page show the equipment of the instrument panel. The
chart may be modified by the minimum equipment require-
ments of individual certifiying authorities.
