Extra 300/SC - Page 231

CHAPTER 31
PAGE 5
MAINTENANCE MANUAL EXTRA 300/SC
PAGE DATE: 1. August 2014
Pos. Item Figure 1
1 12 Volt power source jack
2 COM
3 Air speed indicator
4 Blank
5 Manifold pressure / fuel flow
6 Magn. direction indicator
7 RPM indicator
8 G-meter
9 Trim position indicator
10 Trim position switch
11 Altimeter
12 XPDR
13 ELT switch
14 Ammeter
15 Oil pressure / oil temperature
16 Fuel quantity Rear center tank
17 Fuel quantity Front center tank
18 Fuel quantity Wing tanks
19 EGT / CHT indicator
20 Magneto selector switch & starter
21 Switches, circuit breakers, light as listed below:
Pos. Item Figure2
1 Alternator warning light incl. press-to-test feature
2 Master switch
3 Boost pump circuit breaker switch
4 Strobe lights circuit breaker switch
5 Smoke system switch
6 Overvoltage protection system cicuit breaker
7 Alternator output circuit breaker
8 Smoke system circuit breaker
9 Starter circuit breaker
10 Instruments circuit breaker
11 COM circuit breaker
12 XPDR circuit breaker
13 TRIM circuit breaker
14 12 V circuit breaker
N O T E These lists may be modified by the minimum equipment
requirements of individual certifying authorities!
