CHAPTER 34
PAGE 3
MAINTENANCE MANUAL EXTRA 300/SC
PAGE DATE: 16. June 2008
34-00-00 GENERAL
The EXTRA 300/SC is equipped with an altimeter, an airspeed
indicator and a magnetic compass. Optional a turn and bank
indicator is obtainable. The colour markings in instruments
follow US-FAR, part 23 recommendation.
To get the pitot and static pressure a pitot/static head is
installed at the LH wing leading edge.
