CHAPTER 51
PAGE 5
MAINTENANCE MANUAL EXTRA 300/SC
PAGE DATE: 16. June 2008
GENERAL
Access Panel Identification
Position Ite m
1 Top half of the engine cowling
2 Oil filler access door
3 Main fuselage cover
4 Tail fairing
5 Tail cone access panel (RH)
6 Tail side skin (LH/RH)
7 Cuff (LH/RH)
8 Wheel speed fairing (LH/RH)
9 Bottom half of the enginge cowling
10 Air inlet screen
11 Spinner
12 LH/RH wing tip panel
13 LH/RH outboard access panel
14 LH/RH inboard access panel
15 bottom fuselage cover
