MAINTENANCE MANUAL EXTRA 300/SC
CHAPTER 57
PAGE 6
PAGE DATE: 16. June 2008
Installation
1 Remove the canopy per Chapter 53, the engine cowlings
and the main fuselage cover per Chapter 51.
2 Remove the right front canopy hinge.
3 Loosen the breather line clamps located at the engine side
of the firewall and in the main spar area, push the front part
of the breather line some centimeters to the front until it is
disconnected from the connecting hose (10, Figure 3) and
remove the breather line (5) by pulling it to the rear.
N O T I C E Ensure that areas in which the wing shall be slided are
clear of obstructions.
N O T I C E Prevent cables and pitot/static lines for damage. Keep
them at the rear of the main spar and outside of the up-
per longerons.
N O T I C E Attend to the left front canopy hinge, when sliding down
the wing. The wing could be damaged.
W A R N I N G Beware not to get jammed between wing and fuselage.
4 Slide wing down into fuselage attachment brackets (3).
5 Install LN 9037-08042 auxiliary spar attach bolts (1) from
front to rear. Use two DIN 125-M8 washers and LN 9348-
08 nuts at each side for fastening.
I M P O R T A N T If there is clearance between the main spar and the at-
tachment brackets (1, Figure 2), use shims (3) like
shown below which are to be slided in the front gaps
(2).
