CHAPTER 71
PAGE 4
MAINTENANCE MANUAL EXTRA 330SC
PAGE DATE: 1. August 2014
Removal/Installation
N O T E It is favorable to remove the cowling with two persons.
W A R N I N G Before rotating the propeller in the most convenient
position for removal of the cowling, make sure that the
ignition switch is in the “OFF” position.
1 Rotate the propeller in the most convenient position.
2 Remove the related truss head screws (4)&(5) of top cowl-
ing half (see figure 1).
3 Remove top half of the engine cowling.
4 Remove the remaining truss head screws (4)&(5) of the
bottom cowling half (see figure 1).
5 Remove the bottom half of the cowling.
N O T I C E Pay attention to the rubber/silicon flaps of the air
baffles. Make sure they are not pushed outwards when
installing the top half of the engine cowling.
6 Install in reverse sequence of removal.
