CHAPTER 77
PAGE 6
MAINTENANCE MANUAL EXTRA 300SC
PAGE DATE: 1. August 2014
77-10-21 Manifold Pressure Gauge
Removal/Installation
Refer to Chapter 31.
77-10-22 Sense Line Engine Compartment
Removal/Installation
1 Remove cowling per Chapter 71.
2 Remove clamps if applicable.
3 Disconnect the sense line from the fittings.
4 Remove the sense line.
5 Install in reverse sequence of removal. Torque sense line
fittings with 15.3 to 16.9Nm (135 to 150 inch lbs.) and ap-
ply inspection lacquer.
77-10-23 Sense Line Cockpit
Removal/Installation
Refer to Chapter 20-10-07.
