CHAPTER 91
PAGE 2
MAINTENANCE MANUAL EXTRA 300/SC
PAGE DATE: 1. August 2014
Table of Contents
Figure Title
Chapter 91
EA-9C102B POWER GENERATION/DISTRIBUTION
(UP TO SN SC027)
EA-9C102C POWER GENERATION/DISTRIBUTION
(SN SC028 THRU SC039)
EA-9C102D POWER GENERATION/DISTRIBUTION
(FROM SN SC040)
EA-9C102.2 Magneto System (up to SN SC005)
EA-9C102.2A Magneto System (from SN SC006)
EA-9C102.3A Strobe Light System
EA-9C102.4 Fuel Gages (up to SN SC019 and SC022)
EA-9C102.4A Fuel Gages (from SN SC020 exc. SC022)
EA-9C102.5A COM S/E Gerät
EA-94102.6 Audio Switches & Jacks
EA-9C102.7 Alternator Warning (up to SN SC002)
EA-9C102.7A Alternator Warning (from SN SC003)
EA-9C102.8 Smoke System
EA-9C102.9 Battery Circuit (up to SN SC002)
EA-9C102.9B Battery Circuit (SN SC 003 thru SC027)
EA-9C102.9C Battery Circuit (from SN SC 028)
EA-9C102.10 Alternator System (up to SN SC002)
EA-9C102.10A Alternator System (from SN SC003)
EA-9C102.11 Fuel Boost Pump
EA-94102.14C Pedal Adjustment System
EA-9C102.15 Accelerometer
EA-9C102.16 External Power (up to SN SC002)
EA-9C102.16B External Power (from SN SC003)
EA-93102.18A Batterie Charger System
EA-93102.20A Transponder TRT800-H
EA-93102.22 Transponder BXP6401
EA-93102.26 Transponder ATC4401
EA-9C102.27 Ampere Indication (up to SN SC002)
EA-9C102.27A Ampere Indication (SN SC003 thru SC019 and SC022)
EA-9C102.27B Ampere Indication (from SN SC020 exc. SC022)
EA-93102.28 Fuel Flow EDM700
EA-93102.29 Fuel Flow EDM800
EA-9C102.30 RPM Indication (up to SN SC005)
EA-9C102.30A RPM Indication (from SN SC006)
EA-96102.31 Starter Engaged Light
EA-93102.33 Fuel Flow FS-450
EA-93102.34 Oil Press/Temp Indication
