CHAPTER 08
PAGE 7
MAINTENANCE MANUAL EXTRA 300/SC
PAGE DATE: 16. June 2008
08-20-00 LEVELING
N O T E Level the aircraft only on even floor and in closed halls
(wind protected).
1 Secure each main wheel with two wheel chocks.
W A R N I N G Do not lift tail wheel higher than necessary for leveling.
The aircraft may tilt onto the nose.
N O T I C E Prior to levelling, ensure aircraft is clear of obstruc-
tions.
2 Lift tail and put the jack (height: ~90 cm (~3 ft)) under
the tail wheel, which has to be in the rearmost position.
3 Level the aircraft to its horizontal reference line using
a spirit level (2), which is to put under the bolts of the
rear part of the main fuselage cover (1) (refer to Figure
1). Adjust pitch by changing the jack height.
Leveling
Figure 1
