Chapter 9
ALARMS
Signals
Reason Solution
Display
Indicates the presence of an alarm.
On: indicates the presence of an alarm
O : indicates the absence of alarms
Flashing: indicates the deactivation of the depression sensor.
The alarm can be reset by pressing key 1 for 3 seconds only if
the fumes motor has stopped and if 15 minutes have passed
from displaying the same alarm.
FAN FAILURE
Fault correlated to the  ue exhaust
motor.
The restoration operations must be carried out by an
authorised technician.
FLUE PROBE Fault correlated to the  ue probe.
The restoration operations must be carried out by an
authorised technician.
HIGH GAS
TEMPERATURE
ALARM
The  ue temperature has exceeded
310°C
Check pellet  ow (see “Pellet feed adjustment”).
Check that the machine is clean, including the  ue route.
Avoid resting cloths on the machine.
Other restoration operations must be carried out by an
authorised technician.
DEPRESS INSUFF
The door is not closed correctly.
The ash drawer is not closed
correctly.
The depression sensor is faulty.
The combustion chamber is dirty.
The  ue exhaust pipe is blocked.
Incorrect installation
Check hermetic door closure.
Check hermetic closure of the ash drawer.
Check cleanliness of the fumes pipe and the combustion
chamber.
Other restoration operations must be carried out by an
authorised technician.
NO IGNITION
The pellet feed-box is empty.
Pellet feed calibration inadequate.
Incorrect installation
Check for the presence of pellets in the feed-box.
Adjust pellet  ow (see “Pellet feed adjustment”).
Check the procedures described in the “Ignition” chapter.
Other restoration operations must be carried out by an
authorised technician.
NO IGN
BLACK OUT
No current during the ignition phase.
Take the stove to OFF conditions using key 1 and repeat the
procedure described in the “Ignition” chapter.
Other restoration operations must be carried out by an
authorised technician.
NO PELLET
The  ame went o during work phase,
by lowering the gas too much.
Check for the presence of pellets in the feed-box.
Adjust pellet  ow (see “Pellet feed adjustment”).
Other restoration operations must be carried out by an
authorised technician.
WAIT COOL
Attempt to release the alarm with
stove still in cooling mode.
Every time the stove displays one of the alarms listed above it
will switch-o automatically.
The stove will block any release attempt during this phase,
showing the alarm itself and ATTE alternately on the display.
The alarm can be reset by pressing key 1 for 3 seconds only if
the fumes motor has stopped and if 15 minutes have passed
from displaying the same alarm.
