Confidential and proprietary information of Extreme Networks. © 2011 Extreme Networks, Inc.
All rights reserved. DRAFT. October 20, 2011
Summit Family Switches Hardware Installation Guide
293
C H A P T E R
10
Replacing DC Power Supplies
in Summit Family Switches
This chapter describes how to replace DC power supplies in a Summit X460, X480, X650, or X670 series
switch. These switches have two bays for hot-swappable power supplies. In a switch with a redundant
power configuration, you can replace one Summit DC power supply without powering down
the switch.
This chapter includes the following sections:
● Replacing a Summit 300 W DC Power Supply on page 294
● Replacing a Summit 450 W or 550 W DC Power Supply on page 298
● Replacing a Summit 850 W DC Power Supply on page 304
● Removing an EPS-150DC Power Module from an EPS-T2 Tray on page 308
Read the information in this chapter thoroughly before attempting to replace one of the listed
Summit X650 components.
