Summit Family Switches Hardware Installation Guide
119
Summit 850-Watt AC and DC Power Supplies
The following 850-watt power supplies are available:
● Summit 850 W AC power supply (Model 10914)
● Summit 850 W DC power supply (Model 10915)
These power supplies are compatible with the Summit X650 series switches.
Extreme Networks does not recommended using the Summit 850 W DC power supply in combination with
a Summit 850 W AC power supply in the same Summit X650 series switch.
The Summit 850 W AC and DC power supplies have the status LED described in Table 42.
Table 42: Summit 850 W Power Supply LED
Color and State Meaning
Blinking green AC in; no output
Steady green Normal operation
Blinking red Output error
Steady red Critical error
