Summit Family Switches Hardware Installation Guide
183
C H A P T E R
6
Installing Summit Family
Switches
This chapter describes how to install Summit family switches and associated components. The chapter
also includes information about connecting network interface cables and establishing management
access.
If you intend to use the SummitStack feature, see
Chapter 5 before you install the switches. Chapter 5
provides information about locating stacked switches and connecting the stacking cables.
This chapter includes the following topics:
● Safety Information on page 184
● Installing a Summit Family Switch (Models Other than Summit X460, X480, and X650 Series) on
page 184
● Installing Summit DC-Powered Switches on page 187
● Installing a Summit X460 Series Switch on page 192
● Installing AC Power Supplies in Summit X460 Series Switches on page 195
● Installing a 300 W DC Power Supply in a Summit X460 Series Switch on page 201
● Installing a Summit X480 Series Switch on page 207
● Installing Summit 450 W and 550 W Power Supplies on page 214
● Installing a Summit X650 Series Switch on page 224
● Installing Summit X650 Power Supplies on page 230
● Installing a Summit X670 Series Switch on page 239
● Connecting Network Interface Cables on page 245
● Initial Management Access on page 245
