Figure 8: VIM5-2Q Versatile Interface Module
Table 11: Port Numbers for Ports on the VIM5-2Q Module
ExtremeSwitching VSP4900
Port Number for 48-port Models
49 in unchannelized mode
49/1, 49/2, 49/3, and 49/4 in channelized mode
Expansion Modules
VSP 4900 Series Switches: Hardware Installation Guide 19
