Page #65 background imageLoading...
Page #65 background image
Table 35: Environmental Data
Environmental standards EN/ETSI 300 019-2-1 v2.1.2 (2000 - 2009) - Class 1.2 Storage
EN/ETSI 300 019-2-2 v2.1.2 (1999 - 09) - Class 2.3 Transportation
EN/ETSI 300 019-2-3 v2.1.2 (2003 - 04) - Class 3.1e Operational
EN/ETSI 300 753 (1997-10) - Acoustic Noise
ASTM D3580 Random Vibration Unpackaged 1.5G
Operating conditions Temperature range: 0°C to 50°C (32°F to 122°F)
Humidity: 10% to 95% relative humidity, non-condensing
Altitude: 0 to 3,000 meters (9,850 feet)
Operational shock (half sine): 30 m/s
2
(3 G), 11 ms, 60 shocks
Operational random vibration: 3 to 500 Hz at 1.5 G rms
Storage & transportation
conditions (packaged)
Transportation temperature: -40°C to 70°C (-40°F to 158°F)
Storage and transportation humidity: 10% to 95% relative humidity,
non-condensing
Packaged shock (half sine): 180 m/s
2
(18 G), 6 ms, 600 shocks
Packaged sine vibration: 5 to 62 Hz at velocity 5 mm/s,
62 to 500 Hz at 0.2 G
Packaged random vibration: 5 to 20 Hz at 1.0 ASD w/–3 dB/oct.
from 20 to 200 Hz
14 drops minimum on sides and corners at 42 inches (<15 kg box)
1100 W Power Supplies Technical Specifications
AC Power Supplies
The following 1100 W AC power supply is available for use in VSP 4900 series switches.
1100 W AC power supply: front-to-back airflow (part no. 10941)
Table 36: Physical Specifications
Dimensions Height: 1.57 inches (4.0 cm)
Width: 3.25 inches (8.3 cm)
Length: 10.22 inches (26.0 cm)
Weight 2.55 lb (1.12 kg)
Table 37: Power Specifications
Voltage input range 100-127/200-240 47 to 63Hz
Nominal input ratings 12.5 A max at 115VAC and 6 A max at 230VAC at full 1100 W load
Maximum inrush current 45A at Max 264 VAC at 25C with cold start
Output 54 V, 20 A max, 1100 W
Power supply input socket and cord IEC/EN 60320-1/C16 AC input receptacles
Power cord wall plug Refer to Power Cord Requirements for AC-Powered Switches and AC
Power Supplies on page 66.
Eciency Minimum eciency: 88% at maximum power output.
Technical Specifications
VSP 4900 Series Switches: Hardware Installation Guide 65
