AC power cord. For switches with removable AC power supplies, a separate power cord is needed
for each installed power supply. The cord must meet the requirements listed in Power Cord
Requirements for AC-Powered Switches and AC Power Supplies on page 66.
•
ESD-preventive wrist strap for installing optional ports at the back of the switch.
Attaching the Switch to a Rack or Cabinet
To attach a switch to a two-post rack, a four-post rack, or a cabinet, follow these steps.
Take care to load the rack so that it is not top-heavy. Start installing equipment at the bottom and work
up.
1 On one side of the switch, set a mounting bracket against the switch housing.
Set the flange even with the front panel of the switch – or, if you are mid-mounting the switch in a
two-post rack, set the flange toward the back of the switch.
The following figures illustrate how to attach the brackets for two common mounting options.
•
Figure 13 shows a mid-mount configuration using a long mounting bracket.
•
Figure 14 shows a front-mount configuration using a short mounting bracket.
Note
For some switch models, only short mounting brackets are provided.
Figure 13: Mid-Mount: Attaching a Long Mounting Bracket
Installing Your Switch
VSP 4900 Series Switches: Hardware Installation Guide 37
