IPCP Pro Series • Introduction 5
AUDIO
INPUTS OVER DTP
RS-232
IR
Tx Rx Tx RxG
POWER
12V
0.7A MAX
SIG LINK
DTP OUT
100-240V ~ -- A MAX
1
2
CONFIGURABLE
HDMI
HDMI
5
6
7
8
C
RS-232 IR
RS-232 IR
Tx Rx Tx RxG
Tx Rx Tx RxG
Tx Rx Tx RxG
HDMI
A
B
3
4
INPUTS
OUTPUTS
Tx Rx
RS-232
G
LAN
70V - 100W
RESET
AUDIO INPUTS OUTPUTS
REMOTE
L L1 R R
L 2
R
3
CLASS 2 WIRING
L 4
R
L 5 R
+48V
+48V
1 2
L R
VARIABLE
IN1608 MA
2
MIC/LINE
L 6
R
SIG LINK
DTP IN
SIG LINK
DTP IN
SIG LINK
DTP OUT
50/60 Hz
RS-232 IR
OVER DTP
OVER DTP
OVER DTP
AMPLIFIED OUTPUT
LAN
eBUS
FLEX I/ORELAYSIR/SERIALCOM12 VDC
TxRx G TxRx G Tx Rx G Tx Rx G S G S G S G S G
S G S G S G S G
RTSCTS
IPCP PRO 550
TxRx G TxRx G Tx Rx G Tx Rx G RTSCTS
1.2A MAX
SWITCHED 12 VDC
40W MAX TOTAL
3 4
1 1 2 3 7
8
4 5 6
2 1 2
5 6
3 4
7 8
1 2
5 6
3 4
7 8 321 4 G
+V +S -S G
PWR OUT = 12W
100-240V ~ 50-60Hz
MAC: 00-05-A6-XX-XX-XX S/N: ####### E######
00-05-A6-XX-XX-XX
PUSH PUSH
POWER GUIDE MENU RES 480 480p 720p 1080i1080p
DIRECTV HD
SELECT
DIRECTV
1
INPUTS
AUDIO
Tx Rx G Tx Rx
RS-232 IR
OVER DTP
RS-232
Component HDMI HDMI
HDMI
HDMI HDMI
Audio
Audio Audio
Audio
Blu-ray Player
Tuner
Media Player
PC
Laptop
Flat Panel Display
Flat Panel Display
Microphones
CATx Cable
up to 230' (70 m)
Extron
DTP HDMI 230 D Tx
Transmitter
Extron
DTP HDMI 230 Tx
Transmitter
Extron
IN1608 MA
Scaling
Presentation
Switcher
Extron
FF 220T
Plenum 2' x 2' Flat Field
Ceiling Speakers
Integrated 100 W amplier provides audio coverage for 50' x 40' (15.2 m x 12.2 m) room
Extron
IPCP Pro 550
IP Link Pro
Control Processor
Ethernet
Ethernet/Power
RS-232RS-232
RS-232
IR
Ethernet
Extron
TLP Pro 1520MG
15" Wall Mount
TouchLink Pro
Touchpanel
TCP/IP
Network
Wireless
TouchLink
for iPad
Ethernet
Power
Injector
Figure 4. An IPCPPro550 Application
Device Control
The IPCP must be configured in one of the following ways before it will send commands to a
projector, display, or other device:
• An IR, RS-232, or Ethernet driver file can be downloaded from the Extron website
(www.extron.com/download/index.aspx). The driver is saved to a folder and
commands from the driver are incorporated into the GC configuration file for the control
processor and any touchpanels that will work with it. The configuration file is built and
uploaded to the IPCP via GC.
• If a driver is not already available, RS-232 or Ethernet command strings can be
entered directly from a host computer using GlobalConfigurator. These can then be
incorporated into controls within the GC project.
See the Global Configurator Help file (which comes with the software) for details on setting
up the IPCP and for downloading, programming, or learning device control commands.
•
• IR commands can be entered directly
from an IR remote control through IR
learning via GC to create a driver that
the IPCP can use. IR learning is seldom
needed, but it is convenient for installing
new or updated commands into the
IPCPProSeries in the field in the rare
cases when a driver is not already
available from Extron.
