IPCP Pro Series • Hardware Features and Installation 9
Save and build the project.
Upload the system configuration to the control processor.
Test and Troubleshoot
Test the system. See the Troubleshooting section starting on page30 for an outline
of items to check during system troubleshooting.
Make adjustments to wiring or configuration as needed.
Network Communication Setup
Network setup is essential prior to configuration. Use the flowchart as a guide to setting up
the control processor for network use.
Connect the control processor and PC to the same LAN
and apply power.
Open the Toolbelt software either from within
Global Congurator (GC Professional or GC Plus mode)
or from the stand-alone application.
ToolBelt displays a list of all IP Link Pro devices
connected to the network.
Using the MAC address, locate the desired device
in the list and select it.
Network Communication Setup,
Connected/Online Method
Enable DHCP or you must type in the
IP address, subnet address, and gateway,
then congure other network settings as needed.
Figure 5. Network Setup, Online Method
