IPCP Pro Series • Hardware Features and Installation 24
IPCP Pro Series Control Processor Reset Mode Summary
Mode
Use This
Mode to...
Activation Result
Run/Stop Program
Toggle stop/
start program
To stop or start a program:
1. Hold down the Reset button for about 3 seconds, until the
Power LED blinks once.
2. Release and press the Reset button momentarily (for
<1second) within 1second*.
* Nothing happens if the momentary press does not occur
within 1second.
NOTE: This reset mode is supported on firmware version
2.00.0002-b004 and higher.
The LED flashes 2 times if the program is
starting.
The LED flashes 3 times if the program is
stopping.
Reset All IP Settings
Reset IP
settings and
port maps
to factory
defaults
without
affecting user-
loaded files
To reset all IP settings:
1. Hold down the Reset button for about 6seconds until
the Power LED blinks twice (once at 3 seconds, again at
6seconds).
2. Release and press the Reset button momentarily (for
<1second) within 1second*.
* Nothing happens if the momentary press does not occur
within 1second.
Reset All IP Settings mode:
• Sets the IP address back to factory default
(192.168.254.250)
• Sets the subnet back to factory default
(255.255.255.0)
• Sets the default gateway address to the
factory default (0.0.0.0)
• Sets domain and host names to factory
default
• Sets port mapping back to factory default
• Turns DHCP off
• Turns events (user-created schedules,
macros) off.
Reset to Factory Defaults
Start over with
configuration
and uploading
To reset the unit to all factory default settings:
1. Hold down the Reset button for about 9seconds until the
Power LED blinks three times (once at 3 seconds, again at
6seconds, again at 9 seconds).
2. Release and press the Reset button momentarily (for
<1second) within 1second*.
* Nothing happens if the momentary press does not occur
within 1second.
Reset to Factory Defaults mode performs a
complete reset to factory defaults (except the
firmware).
• Does everything Reset All IP Settings mode
does
• Removes (clears) all user-loaded files and
configurations from the control processor:
• Clears driver-port associations (IR,
serial, Ethernet) and port configurations
• Removes button/touchpanel
configurations
• Removes schedules, settings, macros
