Extron electronics ISM 824 - Command;Response Table for SIS Commands (Continued)

SIS
™
Programming and Control, cont’d
ISM 824 Integration Scaling Multiswitcher • SIS
™
Programming and Control
4-20
Command/response table for SIS commands (continued)
Command ASCII (Telnet)
(host to switcher)
URL Encoded (Web) (host to switcher)
Response (switcher to host)
Additional description
View
X@C X@C X1%]
View current setting.
Tint
Specify a value
X@*X1%T
X@%2AX1% T X@
Tin
X!*X1%]
Sets tint level to
X1%
.
Increment value
X@+T X@+T X@
Tin
X!*X1%]
Increase tint level.
Decrement value
X@-T X@-T X@
Tin
X!*X1%]
Decrease tint level.
View
X@T X@T X1%]
View current setting.
Contrast
Specify a value
X@*X1%^
X@%2AX1% ^ X@
Con
X!*X1%]
Sets contrast level to
X1%
.
Increment value
X@+^ X@+^ X@
Con
X!*X1%]
Increase contrast level.
Decrement value
X@-^ X@-^ X@
Con
X!*X1%]
Decrease contrast level.
View
X@^ X@^ X1%]
View current setting.
Brightness
Specify a value
X@*X1%Y
X@%2AX1% Y X@
Brt
X!*X1%]
Sets brightness level to
X1%
.
Increment value
X@+Y X@+Y X@
Brt
X!*X1%]
Increase brightness level.
Decrement value
X@-Y X@-Y X@
Brt
X!*X1%]
Decrease brightness level.
View
X@Y X@Y X1%]
View current setting.
Detail lter
Set detail level
X@*X1%D
X@%2AX1% D X@
Det
X!*X1%]
Sets detail level to
X1%
.
Increment value
X@+D X@+D X@
Det
X!*X1%]
Increase detail level.
Decrement value
X@-D X@-D X@
Det
X!*X1%]
Decrease detail level.
View detail value
X@D X@D X1%]
View the detail setting.
Horizontal position
Increment value
X@+H X@+H X@
Hph
X!*X1^]
Shift window right.
Decrement value
X@-H X@-H X@
Hph
X!*X1^]
Shift window left.
Vertical position
Increment value
X@+/ X@+/ X@
Vph
X!*X1^]
Shift window up.
Decrement value
X@-/ X@-/ X@
Vph
X!*X1^]
Shift window down.
Horizontal size
Increment value
X@+: X@+: X@
Hsz
X!*X1&]
Widen the window.
Decrement value
X@-: X@-: X@
Hsz
X!*X1&]
Make the window narrower.
Vertical size
Increment value
X@+; X@+; X@
Vsz
X!*X1&]
Make the window taller.
Decrement value
X@-; X@-; X@
Vsz
X!*X1&]
Make the window shorter.
