Mounting
This section outlines the various options for:
• Mounting the TLP Pro 1022M
• Wall Mounting
• Furniture Mounting
• Mounting the TLP Pro 1022T
• Desktop Mounting
• VESA Mounting
Mounting the TLP Pro 1022M
Wall Mounting
The touchpanels can be mounted into drywall.
ATTENTION:
• Do not install the TLP Pro 1022M in a fire resistant rated wall or partition assembly.
• Ne pas installer le TLP Pro 1022M dans un mur résistant au feu ou une cloison.
• All structural steps and electrical installation must be performed by qualified personnel
in accordance with local and national building codes and electrical codes.
• Toute étape structurelle et installation électrique, doit être effectuée par un personnel
qualifié, conformément aux codes du bâtiment, aux codes incendie et sécurité, et aux
codes électriques, locaux et nationaux.
Some local building codes require the touchpanel to be mounted in a wall box such as the
Extron BB 710M (see Mounting with a wall box on the following page).
If local codes permit, you may mount the touchpanel without the wall box (see Mounting
without a wall box on page 20).
