Reference
Material
This section describes:
• Network Port Requirements and Licensed Third-Party Software Used by the
Touchpanels
• Reset Modes
Network Port Requirements and Licensed Third-Party Software Used
by the Touchpanels
For information about network port requirements and licensed third-party software for the
TLP Pro 1022 series touchpanels, please refer to the Pro Series Control Product Network Ports
and Licenses Guide, which is available at www.extron.com.
Reset Modes
The TLP Pro 1022 Series touchpanels have three reset modes that are initiated by pressing the
Reset button:
• Use Factory Firmware
• Reset All IP Settings
• Reset to Factory Defaults
The Reset button is found on the rear panel (see figure 3
B
, on page 5).
Use Factory Firmware
This mode is used to boot up the unit with factory-installed firmware for a single power cycle
in the event of a firmware update that failed or incompatibility issues arising with user-loaded
firmware
Activation
To start the Use Factory Firmware reset mode and replace firmware:
1. On the touchpanel, hold down the recessed Reset button while applying power to the
unit. When power is restored, the Reset LED lights. Hold the Reset button for a further two
seconds before releasing it. The touchpanel enters factory firmware mode.
2. Upload new firmware to the unit as desired (see Updating the Firmware on page 17).
NOTE: Do not continue to operate the touchpanel using the factory firmware version. If
you want to use the factory default firmware, you must upload that version again (see
Updating the Firmware on page 17).
TLP Pro 1022 Series • Reference Material 23
