Colon Insufflator User Manual
Page
8
Section 5.0
DESCRIPTION OF EQUIPMENT
The PROTOCO
2
L™ Colon Insufflator is indicated for use as a means of providing
colonic distention.
5.1
SPECIFICATIONS
Size:
10” wide x 5.50” high x 10” deep.
254 mm x 140 mm x 254 mm
Weight:
Less than 20 lb. (9.0 kg)
Control Panel:
Push
-
buttons and rotary dial. Digital
pressure and
volume readouts.
Gas Flow
:
0 to 3 LPM
Pressure Adjustment:
0 to 25 mm Hg operating.
Pressure Relief Valve:
Electronic controlled relief of pressure at 50 mm Hg
for 5 seconds. Fixed mechanical pressure relief at
75 mm Hg. Both reliefs are
active whether gas flow is
on or off for added protection. Audible alarm will
sound at the time of actuation of the electronic pressure
relief at 50 mm Hg.
Operating modes:
FLOW STOP/RUN
Gas Inlet:
Single “D/E”
CO
2
supply
tank.
WARNING:
Do not allow
liquid CO
2
to enter the unit. This can be prevented by assuring that
the CO
2
supply tank is maintained in a vertical position at all times.
Gas Input Pressure
:
75 to 2200 PSI, flow to 25 PSI.
Patient Set:
Available for use with 0.1 micron hydrophobic fil
ter.
E
-
Z
-
EM, Inc. supplies an Administration Set that
includes this filter.
5.2
ELECTRICAL REQUIREME
NTS
Input Voltage:
100 to 240 VAC nominal line voltage; 50/60 Hz.
(line voltage can vary by ±10% from nominal)
Power:
25 watts, double fusing with removabl
e power cord
Standards:
UL
-
2601
-
1; IEC
-
601
-
1; IEC
-
601
-
1
-
2; EN55011;
EN60601
-
1
-
2; EN50082
-
1; EN61000
-
4
-
2
-
3
-
4
-
5
-
6
-
8
-
11,
EN61000
-
3
-
2
-
3.
