4.4.2 Installing the appliance
1. Turn the 4 legs until they are extended 20 mm
2. Install the appliance with the two front legs
positioned between the supports on the floor plate;
3. Lift the appliance gently over the supports, then put
it down;
4. Make sure that the gas connection isn’t stuck
between the receiver holder and the floor plate
4.4.3 levelling and fixating the appliance
1. Level the appliance in all directions by
adjusting the legs underneath the
appliance;
2. Secure the legs;
3. Secure the appliance to the wall;
4. Install the flue routing as describes in
chapter 5.
4.4.4 Building the false chimney breast
You are now ready to build a false chimney breast
construction. If you purchased the BF110V / Straight
Frameless, you can use the distance holders on top
of the appliance to fixate the construction and keep the builders opening
at a minimum width of 460 mm. Keep in mind that this is measured with
the finishing (e.g. plaster).
Note:
The width of 460 mm of the builders opening is very critical, since
this is the minimum width with which the glass can be taken out. If the
opening is made much wider, the construction of the appliance can
become visible;
Frequently check the distance from the front of the glass to any of the
construction parts of the false chimney breast is at least 12 mm for the
20mm
