UK/IRL
26 < < < <
appliance, follow these steps in reverse order.
Note:
make sure that both handles are moved as far towards
you as possible, otherwise securing the glass won’t be possible.
The glass is protected with a foil which should be removed only
after the whole installation and finishing of the appliance and
false chimney breast is completed.
Make sure that the foil is removed when the appliance is used!
4.5.2 removing/placing the glass of the BF120H / Relaxed
1. Take away the frame of the BF120H / Relaxed (see §4.6).
2. slide the strips on either side of the appliance to the
outside
3. unscrew the screw mounted on the right side of the
appliance which secures a handle (see fig. 3 and 4).
4. Move the handle towards you. The glass is now unsecured.
5. gently grab the glass on either side. Tilt the glass a little
bit backwards. If this not possible, move the handle more
downwards.
6. lift the glass with its top in th false chimney breast.
7. Take the glass out of the false chimney breast.
8. To place the glass back on the appliance, follow these
steps in reverse order.
Note:
when placing the glass make sure that the handle is
moved backwards sufficiently. If this is not the case, securing
the glass will not be possible.
The glass is protected with a foil which should be removed only
after the whole installation and finishing of the appliance and
false chimney breast is completed.
Make sure that the foil is removed when the appliance is used!
1
2
3
4
5
6
