Faber BF110V/Straight - Cleaning the Combustion Chamber and Burner

UK/IRL
38 < < < <
8.1.2 Cleaning the combustion chamber and burner
1. Carefully remove the logs.
2. You can clean the combustion chamber with a vacuum cleaner.
3. Place back the logs as described in paragraph 4.6.
If the burner is visibly damaged, this can affect the distribution of the flame. If so,
then replace the burner.
A. Pilot assembly
B. Burner
C. Fixation plate
D. Injector
E. Gas control
F. Receiver
Logburner
Pebble burner /
Flat fibre burner
