10.4.2 Setting the right transmission code
The receiver has to learn the code from the transmitter. This is already done at the factory.
However the code disappears if the receiver is disconnected from the mains too long.
1. Set the on/off switch on the receiver to "on";
2. Push the "mod" button on the receiver and hold it for 3 seconds;
3. The green control lamp will light up and stay on. Repeat this step if it
doesn't;
4. Push a button on the remote control. The control lamp on the receiver
should now go out;
5. Again push a button on the remote control. The lamp starts flashing
and will switch off eventually;
6. The receiver now recognizes the remote control. The remote control
now functions;
7. Check if you can hear a sound and the motor runs when you push a
button on the remote control.
10.4.3 Changing the batteries
The batteries in the remote control should have a life span of about one
year, depending on the frequency of use.There is no risk of electric shock
as the low voltage supply is similar to that used in torches. Always turn off
the appliance before changing batteries.
Remote control
1. Remove the cover on the back of the remote control;
2. Carefully remove the battery clip along the side. Pay attention not to
pull the wires;
3. If necessary, remove the old batteries and place the new ones:
2x LR03 /AAA Alkaline long life 1.5 V.
4. Click the battery clip into the remote control and close the cover;
5. It might be possible that you have to set the transmission code after changing the
batteries (see 10.4.3).
Note:
Batteries are chemical waste and should be disposed in accordance with local
regulations.
fig. 27 Rear
