4.7 Placing the log set with the log burner
To guarantee good combustion, the log set may only be installed in the way specified on the
picture below. Never place extra elements of any kind into the combustion chamber. This
could affect the combustion in a negative way. Any other arrangement can lead to soot on
logs or window. Do not use the fire with broken or missing logs.
When preferred, ember (immitation-ash) kan be spread around the logs. Attention! Beware
that there are no embers on the air-inlet at the back.
4.8 Placing the pebbles with pebble burner
Spread the pebbles over the bottom plate. To ensure a good combustion, spread the
pebbles equally. Make sure that the pilot burner stays free from the pilot. The pebbles do
not need further servicing. See pictures above for more details
BF110V / Straight log burner
