plaster materials especially made for this, to prevent discoloring (min. 100 °C
temperature resistant);
• Make sure the plaster dries well before using the appliance. Let the thickness in mm
be the number of days the plaster has to dry, e.g. 3 mm plaster has to dry for 3 days.
• Although the appliance is tested for installation without a hearth, the appliance must
not stand on combustible materials or carpets. If the appliance is placed on a
combustible floor first place a fibrelux or similar heatproof board of 12 mm thickness.
Any under floor vents or openings within the builders opening should be sealed off;
• If the floor will be adjusted (e.g. by applying carpet or parquet), the floor under the
false chimney breast has to be adjusted to match the future floor height;
• Do not place any material directly onto the appliance. If possible, apply a lintel made
of cement or something similar;
• Make sure that both the gas control block and the main gas valve are easy accessable
at all times and can be operated if necessary.
Specific requirements for making a false chimney breast for the BF110V / Straight
frameless:
• The front opening of the false chimney breast has to be at least 460mm wide and
1100mm high, measured from the underside of the floor plate;
• Minimum distance from the glass to any of the construction parts of the false chimney
breast should be at least 12 mm. This is the minimum distance with which the glass
can still be taken out;
• When using a material thicker than 12mm, e.g. 50mm thick stony material, the floor
plate has to be adjusted according to the indicated pattern (see paragraph 3.2 for
construction details and dimensions);
Specific requirements for a false chimney breast for the BF110V / Straight with frame
:
• The wall opening has to be 620x1100 mm. This is smaller than the appliance!!!
• The gas control block can be mounted on either the left or right side of the floor plate,
depending on which side makes it easier to acces it.
Specific requirements for a false chimney breast for the BF120H / RELAXED frameless:
• The (wall) opening has to be 1050x425 mm. This is smaller than the appliance;
• The (wall) opening depth is 50 mm. The distance between the opening and the glass
should be at least 12 mm. This is measured after finishing!
