Appendix C – Server Hardware Specifications
 Warning: Be sure to remove all power before servicing the unit. See label
affixed on the TerraBlock unit for power ratings.
Power Supplies
Power supplies are hot-swappable while the server is in operation. Please read the following
procedure for swapping a power supply unit.
1. Locate the failed power supply by the flashing amber light on the unit.
2. Remove the AC power cord from that power supply unit.
3. Press the green tab to the right to free the power supply from the chassis.
4. Pull on the handle to remove the power supply.
5. Slide the new power supply into the slot, and lock into place.
6. Attach AC power cord to the replacement power supply in the chassis.
Dimensions and Weight
Product
Weight with Drives
Depth
Width
Height
TerraBlock
24D/24EX
150/120Lbs
63.5/54.4 Kg
28in
71.1cm
19 in
48.26cm
8 ¾ (5u)
22.2cm
TerraBlock
8D
38lbs
17.23Kg
22 in
55.88 cm
19 in
48.26 cm
3.5 in (2u)
8.89 cm
TX-16
63 Lbs
28.6 Kg
25.6 in
65 cm
19 in
48.26 cm
5.2 in (3u)
13.2 cm
T8
33 Lbs
14.97 Kg
11 1/8 in
28.25 cm
6 5/8 in
16.83 cm
12 in
30.48 cm
Environment
Max Ambient Temp: 30C / 86F
Min Ambient Temp: 5C / 41F
Non-Condensing
Electrical Input
100-240 Vac, 3-1.5 A per power cord
50-60Hz
Auto switching
Multiple power sources. Disconnect all three power cords before servicing. See user guide for
additional Warnings.
24D/24EX
Startup: ~600W
Idle: ~290W
Active: ~415W
8D
Startup: ~250W
Idle: ~120W
Active: ~160W
