PROGRAM EDITING2
The example below shows:
* A possible part-program lay-out in memory indicating the beginning and the end of each
program.
* Various program blocks containing 2, 3, 4 and up to 5 functions. The programming
method does not correspond to this chapter; but it is fully described in the "Programming"
chapter later on in this manual.
In this mode, it is possible to:
* Display the contents of all the memory blocks.
* Create a program (edit all program blocks).
* Delete a particular program block.
* Modify the contents of specific block.
* Replace a particular program block.
* Insert a new program block, shifting the rest of the blocks back.
In the "Aux Mode" it is also possible to:
* Lock the part-program memory.
* Unlock the part-program memory.
* Erase the whole part-program memory.
N000 G1.7.90 F5000 S250 T01 M 3 Beginning of program
N001 X60 Y40
N002 G3 X110 Y90 I0 J50
N003 G3 X160 Y40 I50 J0
N004 M30 End of program
N050 P17 X Beginning of program
N051 P18 Y
N052 P4 F7 P3
N053 P5 F8 P3
N054 P6 P0 F3 P4
N055 P7 P1 F3 P5
N056 G0.5 XP6 YP7
N057 P3 P3 F1 P19
N058 G1 XP6 YP7 F200
N059 P3 F11 K360
N060 G28 N57
N061 G0 XP17 YP18
N062 M30 End of program
N100 G0 X10 Beginning of program
N101 Y20
N102 G1 X50 M3
N103 G0 Y0
N104 X0
N105 G25 N100.104.81
N106 M30 End of program
