PageChapter: 3 Section:
JOG MODE 1
3. JOG MODE
To access this mode, press the key. The top display will appear blank and the
bottom one will show the X axis position.
To change the axis being displayed, press [A+]. The lower display will now show the Y
axis position.
With this operating mode it is possible to:
Move the axes of the machine.
Set Zero or preset a coordinate value (position).
Automatically search home (machine referencing)
Select the CNC to operate as a DRO.
3.1 JOGGING THE AXES
The CNC may be configured in the following ways:
CNC with 1 or 2 axes.
CNC with 1 axis and 1 electronic handwheel.
CNC with 1 or 2 axes and the external operator panel "JOG 100".
CNC with 1 axis, 1 electronic handwheel and the external operator panel "JOG
100".
CNC with 2 axes and auxiliary handwheel
CNC with 2 axes, auxiliary handwheel and the external operator panel "JOG 100"
When moving the axes, the CNC limits their travels according to the setting of machine
parameters P0, P1, P40 and P41.
CNC with 1 or 2 axes
The axes are jogged one at a time. To do that, proceed as follows:
* Select at the lower display, by using the [A+] key, the axis to be jogged (X or Y).
* Use the keys to jog the axis.
The movement will be continuous. In other words, the axis will keep moving while its
jog key is kept pressed.
If pins 14 and 25 of connector I/O2 are used the movements could be continuous or
incremental. In incremental movements the axis will move the predetermined distance.
JOGGING THE AXES
