PageChapter: 3 Section:
JOG MODE 5
3.2 AUTOMATIC POSITIONING
It is carried out one axis at a time by following these steps:
* Select, at the lower display, the axis to be positioned (X or Y) by means of the [A+]
key.
* Press [CL] to clear the lower display.
* Key in the desired destination coordinate (position).
* Press
The CNC will position the axis at the indicated position.
3.3 ZERO SETTING OR COORDINATE PRESET
The coordinate preset is performed one axis at a time by following these steps:
* Select at the lower display, with the [A+] key, the axis to be preset (X or Y).
* Press [CL] to clear the display.
* Key in the desired position value (coordinate).
* Press [ENTER] for the CNC to assume this value.
Press [CL] to cancel this preset before pressing [ENTER] if so desired. In this case,
the CNC will display the previous value again.
AUTOMATIC POSITIONING
