Section:Chapter: 3
Page
JOG MODE4
JOGGING THE AXES
CNC with 1 axis, 1 electronic handwheel and the external operator panel "JOG 100"
The X axis positioning can be done:
* With the electronic handwheel
* By means of push-buttons “X+, X-” associated with the “JOG 100” external
operator panel.
* With the keys on the keyboard.
With the external operator panel "JOG 100", it is possible to select the type of movement
as well as the axis feedrate and the multiplying factor applied by the CNC to the
feedback pulses output by the electronic handwheel.
* While in the "% FEED" positions, the axis movement will be continuous. In other
words, they will move while their jog key is kept pressed.
Each of the positions in this zone displays the percentage feedrate applied by the
CNC in the movement indicated.
* While in the "JOG" positions, the movements will be incremental. In other words,
the axis will move a set distance every time its jog key is pressed.
* While in the position, the axis can only be moved with the electronic handwheel
and each position indicates the multiplying factor applied by the CNC to the
feedback pulses output by the electronic handwheel.
This way, the actual axis jogging units result from multiplying the number of handwheel
pulses by this factor.
Position
Multiplying factor
Example: 250 pulses/turn
Distance per turn
x 1 0.250 mm or 0.0250"
x 10 2.500 mm or 0.2500"
x 100 25.00 mm or 2.500"
