Fagor 101 - Inputs and Outputs

INPUTS AND OUTPUTS
101 101S 102 102S
INPUTS
X axis home switch x x x x
Y axis home switch x x x
External emergency stop x x x x
Feedhold x x x x
External Cycle Start x x x x
External Cycle Stop x x x x
Conditional input (block skip) x x x x
Manual input (DRO mode) x x x x
External Reset (initial CNC conditions) x x x x
2 inputs as Handwheel multiplying factor JOG100 x JOG100
2 inputs for Feedrate override JOG100 x JOG100
5 inputs for parametric programming x x x
2 inputs for handling the auxiliary handwheel x x x
OUTPUTS
8 outputs for M, S or T in BCD or decoded x x x x
M Strobe x x x x
S Strobe x x x
T Strobe x x x
JOG mode selected at the CNC x x x x
Automatic mode selected at the CNC x x x
Internal CNC emergency x x x x
X axis brake x x x x
Y axis brake x x
X axis in position x x x x
Y axis in position x x
X axis Fast (Non-servocontrolled open loop) x JOG 100 x JOG 100
X axis Slow (Non-servocontrolled open loop) x JOG 100 x JOG 100
X direction (Non-servocontrolled open loop) x JOG 100 x JOG 100
Y axis Fast (Non-servocontrolled open loop) JOG 100 x JOG 100
Y axis Slow (Non-servocontrolled open loop) x
Y direction (Non-servocontrolled open loop) x
