PageChapter: 6 Section:
PROGRAMMING 35
PARAMETRIC
PROGRAMMING
F3 Multiplication
N101 P10 P11 F3 P12 Means P10 = P11 x P12
N102 P10 P11 F3 K2 Means P10 = P11 x 2
N103 P10 K8 F3 K2 Means P10 = 8 x 2 = 16
N104 P10 P10 F3 K2 Means P10 = P10 x 2
F4 Division
N101 P10 P11 F4 P12 Means P10 = P11 P12
N102 P10 P11 F4 K2 Means P10 = P11 2
N103 P10 K8 F4 K2 Means P10 = 8 2 = 4
N104 P10 P10 F4 K2 Means P10 = P10 2
F5 Square root
N101 P10 F5 P12 Means P10 = P12
N102 P10 F5 K9 Means P10 = 9 = 3
N104 P10 F5 P10 Means P10 = P10
F6 Square root of sum of squares
N101 P10 P11 F6 P12 Means P10 = P11
2
+ P12
2
N102 P10 P11 F6 K2 Means P10 = P11
2
+ 4
N103 P10 K3 F6 K4 Means P10 = 9 + 16 = 5
N104 P10 P10 F6 K2 Means P10 = P10
2
+ 4
F7 Sine
N101 P10 F7 P12 Means P10 = sine P12
N102 P10 F7 K30 Means P10 = sine 30° = 0,5
F8 Cosine
N101 P10 F8 P12 Means P10 = cos P12
N102 P10 F8 K60 Means P10 = cos 60° = 0,5
F9 Tangent
N101 P10 F9 P12 Means P10 = tan P12
N102 P10 F9 K45 Means P10 = tan 45° = 1
F10 Arc tangent
N101 P10 F10 P12 Means P10 = arc tan P12
N102 P10 F10 K1 Means P10 = arc tan 1 = 45°
