Auxiliary modules
204
4.
AUXILIARY MODULES
External Ballast resistors
198
DDS
HARDWARE
Ref.1310
Use the attached table to select the Ballast resistor for your compact drive
module when applicable with enough rms power to dissipate the energy
generated while braking.
T. H4/9 Possible braking resistors to be installed on compact drive mod-
ules. Required Ohm values.
ACD 1.15 43 300 W Internal R.
CMC 1.15 43 300 W Internal R.
SCD 1.15 43 300 W
Internal R. or external ER+TH-43/350
(with external thermostat)
ACD 1.25 24 250 W 24550 W *
CMC 1.25 24 250 W 24550 W *
SCD 1.25 24 650 W 24 750 W * with external thermostat
SCD 1.25...NR 24 950 W ER+TH-24/1100
ACD 2.35 18 450 W 18900 W *
CMC 2.35 18 450 W 18900 W *
SCD 2.35 18 1.3 kW 18 1800 W * with internal thermostat
SCD 2.35...NR 18
2.0 kW ER+TH-18/2200
2.0 kW ER+TH-18/1000+FAN
3.0 kW ER+TH-18/1500+FAN
4.0 kW ER+TH-18/2000+FAN
ACD 2.50 18 450 W 18900 W *
CMC 2.50 18 450 W 18 900W *
SCD 2.50 18 1.3 kW 18 1800 W * with internal thermostat
SCD 2.50...NR 18
2.0 kW ER+TH-18/2200
2.0 kW ER+TH-18/1000+FAN
3.0 kW ER+TH-18/1500+FAN
4.0 kW ER+TH-18/2000+FAN
SCD 2.75 18 3.0 kW ER+TH-18/1500+FAN *
SCD 2.75...NR 18 4.0 kW ER+TH-18/2000+FAN
* FAGOR supplies the resistors indicated with an asterisk (see shaded
rows) as accessories with the unit. The rest of them are supplied only
upon request.
