DIMENSIONS
Modular drive modules
11.
357
DDS
HARDWARE
Ref.1310
11.3 Modular drive modules
F. H11 /3
Dimensions of the modular drives.
A. AXD/SPD 1.08/1.15, B. AXD/SPD 1.25/1.35, C. AXD/SPD 2., D. AXD/SPD 3..
