CNC 8055 / CNC 8055i
Oscilloscope
function
N
EW
F
EATURES
(S
OFT
M: 7.
XX
)
The machine parameters of the axis or the spindle are updated
according to the criteria defined in the previous tables, the rest of the
parameters are updated according to the general criteria:
If the password to the machine parameters has been defined
(SETUPPSW), it will be requested when modifying a parameter for
the first time. If entered correctly, it is stored in memory and it is not
requested again unless the CNC is turned off. If the password is
wrong, the parameter cannot be modified and it will be requested
again the next time.
When a parameter is changed, the CNC machine parameter table
and the drive's work parameters are updated. The [Save
Parameters] softkey is also activated on the "Configuration -
Parameters" screen.
We suggest to access that screen and press the [Save Parameters]
softkey to save the parameter tables that have been changed, those
of the CNC into the CARDA and those of the drive in its FLASH. If
only the CNC parameters have been changed, the drive tables
remain unchanged and vice versa.
Once the values saved are the same as the ones edited last, the
softkey disappears until a new modification is made.
32.5 Actions
It is available on the following screens: "Parameter Editing",
"Analysis" and "Scales /Offsets".
It is very useful when not having an alpha-numeric keyboard (MC or
MCO operator panels) because it shows several softkeys to change
the data of each field (amplitude of the signals, vertical movement,
time base, position of the cursors, etc.)
32.6 Begin
It is available on the following screens: "Parameter Editing",
"Analysis" and "Scales /Offsets".
It captures data according to the conditions set on the
"Configuration" screen and enables the following softkeys:
Once data capture has ended, or has been interrupted, it is possible
to analyze the signals and modify the parameters that have been
previously selected, in order to improve the machining conditions.
Capture data, analyze it and modify the parameters again until
achieving the best machining conditions.
// It is necessary to press the keystroke sequence: "Shift -
Reset" or turn the CNC off and back on.
/ Just press Reset.
The rest of the parameters (those unmarked) will be updated
automatically, only by changing them.
[Stop]
interrupts the capture and shows the data collected until then.
[Continuous Stop]
available when the capture is continuous. It interrupts the
capture and shows the last full trace.
