CNC 8055 / CNC 8055i
MC model.
Modifications in
the tapping cycle
N
EW
F
EATURES
(S
OFT
M: 7.
XX
)
CODISET (P147)
This parameter has 16 bits counted from left to right.
Bit 16 indicates whether the operations or cycles of the MC model
have auxiliary M functions associated with roughing and finishing
operations.
39 MC model. Modifications in the tapping cycle
From this version on, it is possible to specify the thread by defining
the pitch (p) the spindle speed (S) or the feedrate (F) and the spindle
speed (S).
To do that, the "Penetration" area shows an icon with 2 states [p, S]
and [F, S]. To select the desired one, place the cursor over the icon
and press the (a) key, this will enable the fields selected to define it.
40 MC model. Modifications in the Multiple milling and
positioning cycles
All the modifications or improvements have to do with the definition
of intermediate points of the profile milling cycle (level 1) and the
cycle for multiple positioning of several points.
Repeat previous
coordinate
If a coordinate is left blank, the cycle will assume that it is a repetition
of the previous one. Example:
Incremental
coordinates
The coordinates of each point may also be defined incrementally. To
do that, position over the desired coordinate and press the (a) key.
The X and Z coordinates of the selected point will be shown
preceded by the “∆” icon that indicates the incremental value with
respect to the previous point.
41 MC model. Icon indicating the available options
The multiple positioning in line, arc (level 1), in grid pattern and in
rectangular pattern may be defined in different ways.
In this cases, an icon is added showing the selected option and the
number of total options available. For example [1 of 3].
To select another option, place the cursor over the icon and press
the (a) key.
(0) They do not have auxiliary M functions
(1) They do not have auxiliary M functions
By default 0 (they do not have them)
(a)
X1 25.323 Y1 26.557
X2 Y2 78.998 Point X2 25.323 Y2 78.998
X3 67.441 Y3 83.231 Point X3 67.441 Y3 83.231
X4 Y4
X5 Y5 There are no more points, it is a
repetition of the previous point
