CNC 8055 / CNC 8055i
MC model. Cycle
selection
N
EW
F
EATURES
(S
OFT
M: 7.
XX
)
Program in execution or interrupted.
When editing the active tool, it is possible:
To modify the I and K data.
Select another tool (T xx Recall) and modify its I and K data.
When NOT editing the active tool, it is possible:
To modify the I, K and D data.
Select another tool (T xx Recall) and modify its I, K and D data.
Program in tool inspection.
When editing the active tool, it is possible:
To modify the I and K data.
Select another tool (T xx Recall) and modify its I and K data.
Change the active tool (T xx Start).
When NOT editing the active tool, it is possible:
To modify the I, K and D data.
Select another tool (T xx Recall) and modify its I, K and D data.
Change the active tool (T xx Start).
Rest of cases (program neither in execution nor in tool inspetion)
When editing the active tool, it is possible:
Modify all the data.
Change the active tool (T xx Start).
When NOT editing the active tool, it is possible:
Modify all the data except the part dimensions.
Change the active tool (T xx Start).
The I and K values
The values entered in the I, K fields are incremental, they are added
to the ones already in the table. The "I" data is given in diameter.
The new g.m.p. “MAXOFFI (P165)” and “MAXOFFK (P166)” indicate
the maximum value that may be entered in each field. When trying
to enter a greater value, the relevant message will be displayed.
Warning
37 MC model. Cycle selection
From this version on, it is possible to hide unused operations or
cycles and only show the used ones.
To assume the new I and K values, select the tool again.
