AC Brushless Servo Drive System Manual Ver: 0002
ACa - 11 / 32
Preliminary
2.2 GENERAL CHARACTERISTICS.
(*) IP20 means that it is protected against particles with a diameter greater than 12.5 mm but
it doesn't against water splashes. The module must be located into the electrical cabinet.
2.3 CONNECTORS
Power Terminals
POWER INPUTS 220Vac, L1, L2, L3: Main Power Supply terminals.
POWER OUTPUTS, U, V, W: Motor power output terminals.
Current control through PWM. Carry wave frequency of 10 kHz.
Connect the phases between the motor and drive this way, U-U, V-V and W-W.
L+, Ri, Re: External Ballast terminals.
CONTROL POWER INPUTS 220Vac, L, N, Ground: Auxiliar Power Supply terminals.
The maximum cable section at these power terminals is: 2.5 mm
2
.
Total isolation between power and control circuits.
Fagor A.C.S. Drive
ACS-05 ACS-10 ACS-20 ACS-30
Rated output current 2,5 Amp-rms- 5 Amp-rms- 10 Amp-rms- 15 Amp-rms-
Peak output current (0.5 sec) 5 Amp-rms- 10 Amp-rms- 20 Amp-rms- 30 Amp-rms-
Power supply Three-phasic mains 50/60 Hz, from
220Vac -15% to 240Vac +10%
Consumption, Amp 2,5 Amp-rms- 5 Amp-rms- 10 Amp-rms- 15 Amp-rms-
Overvoltage protection 430 Vdc
Internal Ballast 112 Ohms 56 Ohms 28 Ohms 18 Ohms
Internal Ballast power 200 W
Ballast turn-on 416 Vdc
Heat-sink thermal protection 90°C (194°F)
Working Ambient temperature 5°C / 45°C (41°F / 113°F)
Storage temperature -20°C / 60°C (-4°F / 140°F)
Protection degree IP20 (*)
Module dimensions 67 x 280 x 245 mm
(2.48 x 11.8 x 9.05 inches)
Module weigth 3,85 Kg (8,5 lbs)
