FXM 34.20F . I0 . 0 0 0
F
AGOR A
X
IS
M
OTOR
I0
Incremental Encoder
Example:
FXM MOTORS
SIZE
1, 3, 5, 7
F
12
1200 rpm
20
2000 rpm
30
3000 rpm
40
4000 rpm
LENGTH
MAXIMUM
SPEED
WINDING
FEEDBACK TYPE
FLANGE AND
SHAFT
0
With Keyway
1
Without Keyway
BRAKE OPTION
0
Without brake
1
With standard brake (24 Vdc)
VENTILATION
0
Without Fan
1.5 SALES REFERENCE
1.4 BRAKE CHARACTERISTICS
Motor Type
Torque
Maximum
RPM
Power
On/Off
Delay
Unlocking
voltage margin
Inertia Weight
Nm (in.lb) rpm W (HP) ms Vdc Kg.cm
2
(lb.in
2
) Kg (lbf)
FXM 1 2.5 (22.12) 10000 12 (0.016) 7/5
22 - 26
0,38 (0.13) 0,3 (0.66)
FXM 3 5 (44.25) 8000 16 (0.021) 15/7 1,06 (0.36) 0,6 (1.32)
FXM 5 12 (106.2) 6000 18 (0.024) 30/13 3,6 (1.23) 1.1 (2.42)
FXM 7 40 (354) 3600 35 (0.047) 100/30 31,8 (10.86) 3.5 (7.71)
