AC Brushless Servo Drive System Manual Ver: 0002
ACa - 19 / 32
Preliminary
These are the names of the identity
modules (IM) for each Motor-Drive set.
And these are the values of the passive
components on each of those cards.
IDENTITY MODULE Example: IM - 3420F - 10
IDENTITY MODULE
MOTOR TYPE
DRIVE TYPE
MI Board
RIT RAJFV
ACS-05 ACS-10 ACS-20 ACS-30
FXM11.40F.I0.xx0
IM-1140F-05 Open 6,2K
FXM12.40F.I0.xx0
IM-1240F-05 470K 6,2K
FXM13.40F.I0.xx0
IM-1340F-05 IM-1340F-10 220K 6,2K
FXM14.20F.I0.xx0
IM-1420F-05 470K 12K
FXM14.40F.I0.xx0
IM-1440F-10 120K 6,2K
FXM31.20F.I0.xx0
IM-3120F-05 470K 12K
FXM31.40F.I0.xx0
IM-3140F-05 IM-3140F-10 220K 6,2K
FXM32.20F.I0.xx0
IM-3220F-05 IM-3220F-10 220K 12K
FXM32.40F.I0.xx0
IM-3240F-10 IM-3240F-20 68K 6,2K
FXM33.20F.I0.xx0
IM-3320F-10 IM-3320F-20 100K 12K
FXM33.40F.I0.xx0
IM-3340F-20 39K 6,2K
FXM34.20F.I0.xx0
IM-3420F-10 IM-3420F-20 68K 12K
FXM34.40F.I0.xx0
IM-3440F-20 18K 6,2K
FXM53.20F.I0.xx0
IM-5320F-20 IM-5320F-30 47K 12K
FXM53.40F.I0.xx0
IM-5340F-30 12K 6,2K
FXM54.20F.I0.xx0
IM-5420F-20 IM-5420F-30 27K 12K
FXM54.30F.I0.xx0
IM-5430F-30 12K 8,2K
FXM55.12F.I0.xx0
IM-5512F-20 IM-5512F-30 47K 20K
FXM55.20F.I0.xx0
IM-5520F-30 15K 12K
FXM73.12F.I0.xx0
IM-7312F-20 IM-7312F-30 39K 20K
FXM73.20F.I0.xx0
IM-7320F-30 12K 12K
FXM74.12F.I0.xx0
IM-7412F-20 IM-7412F-30 18K 20K
FXM75.12F.I0.xx0
IM-7512F-30 12K 20K
RAP1 = 82K CAI1 = 100nF RAPT = Open
