14
6.3 ELECTRIC SUPPLY & CONNECTION
The location of the electrical connection is as seen in section 5.0. this unit is suitable for AC
supplies only.
To install the mains cable, remove rear fan cover and terminal cover panel as shown below
and feed the cable through the cable gland(s) and connect the mains supply to the terminal
block(s).
On Model E163i The standard terminal arrangement is Three phase (400V 3N~).
Install an appropriate three phase mains supply cable with a 32amp plug.
