Setup:
Caution!
To prevent electric shock and damage to the device, make sure the power is switched OFF
on the drum and all related device before making any connection.
Connecting the Pads and the Pedals
Standard configuration:
KICK, SNARE (Double trigger), TOM 1~3, CRASH 1 (Choke), RIDE (Choke), HI-HAT,
PEDAL (HI-HAT).
Note:
1. Using the cables provided, connect each Trigger input jack on the rear panel of the
module, and make sure each pad is connected to its corresponding trigger input jack.
2. For details on assembling the drum stand, attaching the digital drum and connecting pads,
refer to the Installation Manual description.
