9
Turn the locking ring counter clockwise for a tight t.
Side mounting:
On both sides of the wheel base are
two M8-threaded holes which are 20mm
deep:
Bottom mounting:
On the underside of the wheel base are ve
M6-threaded hole patterns which are 12mm deep
for Fanatec triangular mounting and square mount-
ing (78,4mm x 66mm):
Using the front centre hole with the two rear holes
(Fanatec Triangular mounting - marked with gold
arrows) is sufcient for use.
Fanatec offer optional Podium Mounting Brackets for side mounting, and the
ClubSport Table Clamp V2 can also be used. Fanatec pedals are required for
operation on PS4™. You can obtain these add-on products from the Fanatec
webshop: www.fanatec.com
