Fantech SHR 1505R User Manual (English)

Questions and Answers:

J
Justin HollowayAug 4, 2025
What to do if Fantech Fan has poor air flows?
- R
  Rebecca WoodAug 4, 2025
  If your Fantech Fan has poor air flows, you can try the following: * Clean exterior hoods or vents if the 1/4" (6mm) mesh on the outside hoods is plugged. * Remove and clean the filter if filters are plugged. * Remove and clean the core if it is obstructed. * Check and open indoor grilles if they are closed or blocked. Also, ensure that an electrician checks the supply voltage if there is an inadequate power supply at the site and check duct installation if ductwork is restricting airflow. Increase the speed of the HRV if there is an improper speed control setting. If the HRV airflow is improperly balanced or ducting has fallen down or been disconnected from the HRV, have a contractor address these issues.
D
David ThomasAug 12, 2025
Why is my Fantech SHR 1505R Fan supply air feels cold?
- U
  upatelAug 12, 2025
  If the supply air from your Fantech Fan feels cold, it could be due to the following reasons: * The location of supply grilles may be causing airflow to irritate occupants. Relocate the grilles high on the walls or under the baseboards, and install ceiling-mounted diffusers or grilles to avoid directly spilling supply air on occupants. You can also turn down the HRV supply speed. A small duct heater (1kW) could be used to temper the supply air. Ensure that furniture placement or closed doors are not restricting air movement. * If the outdoor temperature is extremely cold, and supply air is ducted into the furnace return, the furnace fan may need to run continuously to distribute ventilation air comfortably.
M
monicathomasAug 17, 2025
What to do if Fantech SHR 1505R Fan has persistent condensation on window?
- C
  Christina PhillipsAug 17, 2025
  If you notice persistent condensation on windows when using your Fantech Fan, consider the following: * Reduce the desired level of humidity, if there is an improper adjustment of the dehumidistat control, and combine this step with the use of continuous exchange mode. * Have a contractor balance the HRV if the HRV is out of balance. * Open curtains or blinds to improve air circulation near windows.
A
Ann CainAug 21, 2025
How to fix HRV and/or Ducts frosting up in Fantech SHR 1505R?
- J
  Jennifer HernandezAug 21, 2025
  If your Fantech Fan's HRV and/or ducts are frosting up, consider these solutions: * Have an HVAC contractor balance the HRV airflows if the HRV air flows are improperly balanced. * Note that minimal frost build-up is expected on cores before the unit initiates defrost cycle functions, if there is a malfunction of the HRV defrost system.
J
Justin JenkinsAug 26, 2025
What to do if Fantech Fan air is too dry?
- D
  Daniel WestAug 26, 2025
  If the air is too dry when using your Fantech Fan, increase the desired level of humidity if the dehumidistat control is set too low. Also, change the ventilation mode from continuous mode to standby.
R
Richard BernardAug 29, 2025
How to fix Condensation or Ice Build Up in Insulated Duct to the Outside in Fantech SHR 1505R?
- J
  jenniferlyonsAug 29, 2025
  To address condensation or ice build-up in the insulated duct to the outside of your Fantech Fan, tape and seal all joints if there is an incomplete vapor barrier around the insulated duct. Also, tape any holes or tears made in the outer duct covering and ensure that the vapor barrier is completely sealed if there is a hole or tear in the outer duct covering.

Fantech SHR 1505R Specifications

General

Brand	Fantech
Model	SHR 1505R
Category	Fan
Language	English

Summary

Important Installation Warning

Determining Airflow Requirement

Room Count Method

Method for calculating ventilation airflow based on room classification and count.

ASHRAE Method

Ventilation air requirements based on floor area and number of bedrooms as per ASHRAE.

Installation Examples

Fully Dedicated System

Installation for new construction, supplying fresh air to main living areas.

Partially Dedicated System

Connecting fresh air to the return plenum of the air handler.

Simplified Installation - Option 1

Connecting both supply and exhaust air streams to the furnace cold air return.

Simplified Installation - Option 2

Connecting supply air to furnace supply side and exhaust to cold air return.

Exterior Ducting Installation

Weatherhood Location

Guidelines for locating intake and exhaust weatherhoods outside the building.

Installing Ducting to Weatherhoods

Instructions for connecting flexible insulated ducting to weatherhoods.

Steps for Hood Installation

Step-by-step guide for mounting hoods to the exterior wall.

Interior Ducting Installation

Installing Ducting to HRV

Procedure for connecting flexible or solid ducting to the HRV unit.

Supply Air Grilles Location

Guidance on locating supply air grilles in various home configurations.

Exhaust Air Grilles Location

Recommendations for exhaust air grille placement in high-moisture/odor areas.

Ducting Fifth Port Units

Instructions for connecting the fifth port for defrost/recirculation modes.

Ducting Installation Examples

Fully Dedicated System Diagram

Diagram illustrating the fully dedicated system ducting.

Partially Dedicated System Diagram

Diagram showing the partially dedicated system ducting.

Simplified Installation - Option 1 Diagram

Diagram for simplified installation option 1 (return/return method).

Simplified Installation - Option 2 Diagram

Diagram for simplified installation option 2 (supply/cold air return method).

HRV Installation

HRV Location Considerations

Guidance on selecting an appropriate conditioned space for HRV placement.

HRV Mounting Procedure

Step-by-step instructions for securely mounting the HRV unit using hanging hardware.

Installing Drain Line

Instructions for installing the condensate drain line with a P-trap.

Start Up Procedure

Airflow Balancing

Adjusting Airflows

Information on the integrated damper for adjusting fresh air intake.

Measuring Airflow Using Station Method

Procedure for measuring airflow velocity using a flow measuring station.

Low Voltage Control Systems

Central Controls

Overview of individual central control options for the HRV system.

Auxiliary Controls

Description of auxiliary controls that can be paired with the HRV system.

Electrical Connections

Electrical Connections for SHR/VHR 1500/2000 Series

Wiring diagram for specific SHR and VHR models, including jumper settings.

Electrical Connections for SHR3005R

Wiring diagram for the SHR3005R model, including jumper settings.

Electrical Connections for SHR3205RD

Wiring diagram for the SHR3205RD model, including jumper settings.

Electrical Connection to Furnace

Details on connecting the HRV to a furnace for heating and cooling systems.

Troubleshooting

HRV Maintenance Chart

Limited Warranty Information

Details on the warranty coverage, limitations, and purchaser responsibilities.
